Product Details:
|
| Item Name: | Safety Pen Needle 30G 4mm With Thin Wall Technology For Insulin Injection | Gauge: | 30G |
|---|---|---|---|
| Length: | 4mm | Type: | Safety Pen Needle (SPN) |
| Material: | PE+PP+Stainless Steel | Needle: | Triple Beveled Tip, Silicon Coating |
| Sterilization: | Gamma Or Electron Beam Irradiation | Classification: | Medical Device Class III |
| Application: | Diabetic Patients | OEM: | Available |
| High Light: | 29G disposable insulin pen needles,4mm safety pen needles,CFDA disposable insulin pen needles |
||
【Safety Pen Needle Introductions】
Safety insulin pen needles offer easy and intuitive handling with no special training required. The clear shield allows for visibility of insulin needle tip during priming and automatically protects the needle before and after use. Safety mechanism is smoothly engaged during injection and insulin pen needle is permanently shielded to prevent accidental needle-stick injuries.
【Safety Pen Needle Specifications】
| Type | Safety Pen Needles |
| Material | PE+PP+Stainless Steel |
| Gauge | 30G-32G |
| Length |
4MM-12MM
|
| Sterilization |
Gamma or Electron Beam Irradiation
|
| OEM |
Available
|
| HS Code |
9018321000
|
| Shelf Life | 5 Years |
| Package | 100 Pcs/Box, 40 Boxes/Ctn |
| Certificates | ISO13485(TUV), MDR CE (TUV), US FDA, US FDA 510K, UK MHRA |
| Intended Use | Match with insulin pen for insulin injection to lower the blood sugar level. |
【Safety Pen Needle Features】
Diabetic safety needle is irradiation sterilized and individual sealed to ensure 5 years of shelf life
Safety insulin needle is hidden from view before and after use for a less intimidating experience.
Auto retractable insulin pen needle is compatible with most insulin pens.
Triple beveled needle with silicone coating aims to painfree injection.
Insulin pen safety needle adopts thin wall technology for smooth and quick liquid injection.
【Safety Pen Needle Safety Indicator】
The red indicator shows after injection. It means the safety pen needle can't be used again.
【IFU for Safety Pen Needle】
Step 1: Remove the protective seal.
Step 2: Screw the needle onto the pen injector. Keep the needle straight without any damages.
Step 3: Remove the pen needle outer cover and dispose it into an appropriate container.
Step 4: Upward the needle, flick the pen injector to float the bubbles to the needle top, press the injection button until the liquid is discharged from the needle tip.
Step 5: Make an injection per physician's advice. After injection, keep the needle under the skin for at least 6 seconds before pulling out.
Step 6: Discard the used safety pen needle into the appreciate container.
【Safety Pen Needle Production】
【Safety Pen Needle Compatibility】
The pen needle can be used with insulin pens that meet the requirements of ISO 11608-1, for example: Autopen, Flexpen, Novopen Echo / Novopen 4, Humapen Ergo / Humapen Luxura / Humapen Memoir, KwikPen, Solostar, ClickStar, SymlinPen etc.
【Safety Pen Needle Storage】
The safety needle for insulin pen should be stored in a well-ventilated room and kept away from light and moisture and corrosive gases.
【Safety Pen Needle Warning】
1. The insulin injection pen needle 30G 4mm should be used immediately after the seal is removed. Please do NOT use the pen needle if the seal is damaged or broken previously.
2. This diabetic pen needle is sterilized by irradiation and is designed for single use. Re-use may lead to mechanical malfunction and potential microbiological contamination.
3. Please read the user manual carefully before use.
4. The diabetic safety needle is only intended for using with insulin injection pen.
5. Keep insulin pen needles out of the reach of children.
6. Do not share your needles with other people which can lead to the transmission of viral diseases. You may give other people a serious infection or get a serious infection from them.
7. Do not insert the pen needle at an angle towards your fingers, this may result in a needle-stick injury.
8. In the event of any serious adverse event, please report to the manufacturer and the competent authority.
